Hypex NC502MP 4-Channel
Orders typically ship within 7-10 days
All amplifiers are individually assembled and tested to ensure the highest quality and performance.
$1,125.00Buy Now
Power
- 450 watts @ 2 ohm
- 500 watts @ 4 ohm
- 350 watts @ 8 ohm
- (per channel, 1kHz, 1% THD)
Fidelity
- S/N: 124dB
- FR: 10Hz - 48KHz
- THD: 0.0018% (250W, 4Ω, 10Hz-20kHz)
Free US Shipping
International customers please contact us before ordering.
Utilizing two Hypex NC502MP NCORE modules, this is the perfect 4-channel amplifier for those with large Front LCR setups, such as Magnepan owners. Or those with very demanding surround/height speaker setups. Enjoy sound that is faithful to the source thanks to flat frequency response and low distortion.
The Hypex NC502MP NCORE is an all-in-one dual channel amplifier module. The entire topology, including incorporated SMPS, was designed by Hypex for up to 500 watts of power per channel (all channels driven) at incredibly low levels of distortion and noise floor.
NOTE: While we understand the hesitation by some to use a 4ch amplifier for 3ch duty (such as Front LCR speakers), there are no performance issues with leaving one channel unused.
Please see our FAQ section for more information if necessary.
The Hypex NC502MP NCORE is an all-in-one dual channel amplifier module. The entire topology, including incorporated SMPS, was designed by Hypex for up to 500 watts of power per channel (all channels driven) at incredibly low levels of distortion and noise floor.
NOTE: While we understand the hesitation by some to use a 4ch amplifier for 3ch duty (such as Front LCR speakers), there are no performance issues with leaving one channel unused.
Please see our FAQ section for more information if necessary.
Custom I/O Board:
- Neutrik XLR connectors
- Gold plated 5-way speaker binding posts
- Auto Sensing On/Off
- 12v trigger On/Off
- Muted soft-start/shutdown (minimizes speaker “pop” when turning on and off)
- Clipping Indication (via front power LED)
- Error Indication (via front power LED)
RCA vs. XLR
While our amplifiers use XLR inputs, it is perfectly fine (and fully supported by Hypex) for customers to use RCA to XLR cables to connect the amplifier to a source that only has RCA outputs.
Please see our FAQ section for more information if necessary.
While our amplifiers use XLR inputs, it is perfectly fine (and fully supported by Hypex) for customers to use RCA to XLR cables to connect the amplifier to a source that only has RCA outputs.
Please see our FAQ section for more information if necessary.
Specifications:
- (2) Hypex NC502MP modules
- High Input Impedance: 47K
- High Damping Factor
- High 27A Output Current (per channel)
- 26dB Voltage Gain
- Input Sensitivity: 2.3Vrms (4ohm) / 2.7Vrms (8ohm)
- 0.5W standby operation
- Efficiency = 92%
- All aluminum case w/black powder coat finish
- 12" wide x 13" deep x 3.5" high, 12lbs
Our cases may not be much to look at, but unlike our competitors who use overseas manufacturing, we have all of our cases manufactured in Nova Scotia, Canada (Protocase, Inc). This is part of our commitment to keep as much of our amplifiers as "home grown" as possible. It also ensures the highest possible quality aluminum and extremely precise CNC manufacturing.
Options:
- See our case options for case upgrades.
- See our connector options for connector upgrades.
